Pole hoist Davit
AFT751080 AFT751080

Pole hoist Davit

AFT751080-EXTREME-Pole-Hoist-Davit-TDS-DA08-1 AFT751080-DA08-KS-ASIA DOC-AFT751080

The KSTRONG AFT751080 Pole Hoist Davit, part of the EXTREME Series, is designed for confined space vertical and horizontal entry and rescue operations.

This 3-stage adjustable davit arm features a high-strength aluminum alloy body with dual-color powder coating for durability and corrosion resistance.

Certified to EN 795:2012 Type A and AS/NZS 5532:2013, the AFT751080 supports up to 140 kg user weight and is compatible with KSTRONG manual winches and retrieval blocks.

For horizontal applications, it can be fixed via the optional flange adapter AFT730013, making it a robust solution for edge entry and overhead-limited spaces.

Brand KSTRONG UNRIVALED SAFETY
P/NAFT751080

Specifications & Material

  • Model: AFT751080
  • Material: High-strength aluminum alloy
  • Finish: Dual-tone black and grey powder coating
  • Weight: Approx. 13.19 kg ± 0.10 kg
  • Extension range: 2017mm to 2634mm (3-position arm)

Certifications & Safety Performance

  • Certified to EN 795:2012 Type A and AS/NZS 5532:2013
  • Static strength test: 15kN
  • Max user weight: 140 kg (single user only)
  • Application: Fall protection anchorage and rescue—not for material lifting

Weight & Comfort

  • Lightweight aluminum construction for portable deployment
  • Modular components allow for easy transport and setup

Design Features

  • Swivel eye at arm tip for secure anchorage
  • 3-position adjustable arm for versatile entry configuration
  • Ideal for overhead-limited side entries

Applicable Scenarios

  • Confined space entries (manholes, hatches, ledges)
  • Oil & gas, construction, shipyards, water works rescue operations

Strength Rating

  • Flange adapter (AFT730013) supports up to 23kN
  • Requires M35 hole spacing and high-tensile bolts for anchoring
